Oil & Chemical Resistant Conveyor Belts for Recycling & Chemical Plants

Oil Resistant Conveyor Belt

JINFLEX oil resistant conveyor belts are designed for transporting oil-contaminated or oil-treated materials, widely used in chemical plants, paper mills, fertilizer plants, mines, ports, and oil refineries—suitable for conveying asphalt, oil-containing coal, petroleum coke, and oil-impregnated waste.

Our oil resistant conveyor belts comply with China’s industrial standards (HG/T3714, HG4-846) and international standards, including the United States (RMA MOR/OR), Germany (DIN22131), Japan (JIS6369), Australia (AS1333), and South Africa (SABS).

Product description

The oil resistant conveyor belt features an "oil-proof cover rubber + anti-oil infiltration carcass + oil-resistant core rubber" structure, solving oil-induced rubber swelling:

Oil Resistant Cover Rubber:

High-performance synthetic rubber (nitrile rubber blend) with oil swelling rate ≤15% (after 72h immersion in 40℃ engine oil), effectively resisting oil erosion.

Carcass:

Multi-ply fabric (EP/NN/CC) with anti-oil coating on the surface, preventing oil from penetrating into the belt core and weakening tensile strength.

Core Rubber:

Oil-resistant core rubber with strong adhesion to carcass, ensuring layer bonding strength ≥8.0N/mm even after oil contact.

Edge Sealing:

Sealed edge rubber blocks oil from entering the belt edge, avoiding edge hardening or cracking.

Features and Benefits

■ Excellent Oil Resistance

Cover rubber swells ≤15% and hardness change ≤10 Shore A after 72h immersion in 40℃ engine oil; no rubber peeling or carcass corrosion in long-term oil contact.

■ High Tensile & Impact Resistance

EP/NN carcass has low elongation (≤1.5%) and high modulus, bearing heavy oil-containing materials (e.g., asphalt, 2.5t/m³); impact resistance ≥50kJ/m².

■ Good Flexibility & Troughability

Adapts to small-diameter conveyor rollers (minimum 150mm), suitable for mobile conveying equipment in oil refineries; stable trough formation ensures uniform material transport.

■ Wide Temperature Adaptability

Works normally at -20℃~80℃, no hardening in low temperature or softening in high temperature—suitable for both indoor workshops and outdoor ports.

■ Easy Maintenance

Oil-resistant surface is easy to clean; cover rubber wear rate ≤0.1mm/month, reducing replacement frequency.

Belt Selection

Carcass Type: Polyester/Polyimide (EP), Nylon/Nylon (NN), Cotton/Cotton (CC)

Tensile Strength: 56N/mm (CC56) - 400N/mm (EP/NN 400)

Belt Width: 400mm - 2200mm

Cover Thickness: 2-12mm (top/bottom optional)

Special Options: Combined oil-heat resistance (≤125℃), oil-flame resistance (MT668)

Why Choose Us

Support small-batch orders with no MOQ：

backed by 20M meters annual capacity, we deliver small batches (e.g., refinery trial, equipment matching) on time.

Offer full customization:

Customize cover rubber oil resistance level (for light/heavy oil), belt width, and carcass material according to your oil-containing materials.

Deliver high cost-effectiveness:

50+ years of rubber product experience, ISO/CE certification, and optimized oil-resistant formula ensure long life at an economical price.

Reference Specification:

Carcass Type	Oil Resistance Level	Applicable Oil Type	Tensile Strength (N/mm)	Belt Width (mm)	Cover Thickness (mm)	Oil Swelling Rate (%)	Operating Temperature （℃）
					Top	Bottom	(40℃ engine oil, 72h)
CC56/70	Standard	Light oil (gasoline, diesel)	56/70	400-2200	2-6	2-4	≤15
EP/NN 100-200	Standard	Light oil (gasoline, diesel)	100-200	400-2200	3-8	2-6	≤15
EP/NN 250-400	High	Heavy oil (asphalt, petroleum coke)	250-400	400-2200	4-12	3-8	≤12
EP/NN 100-400	Oil-Heat Resistant	Heavy oil (asphalt, hot oil)	100-400	400-2200	4-12	3-8	≤12

This table is for reference only. Please consult JINFLEX business personnel for details
